5-Port Gigabit Switch, 4 PoE ports

Expand your available network connections with a PoE Gigabit Switch

5 × 10/100/1000Mbps Auto-negotiation Gigabit RJ45 ports with 4 ports of PoE function (port 1 - port 4)
Supports total PoE power up to 75W for all PoE ports
Supports PoE power up to 26W for each PoE port
Supports PoE IEEE802.3af and IEEE802.3at compliant Powered Device (PD)
Supports IEEE802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
8K entry MAC address table of the switch with auto-learning and auto-aging
LED indicators for monitoring power, link, activity, POE
Internal power supply
19" rack mountable

EM4435

| Add to Compare

Product Description

Details

Expand your available network connections with the Eminent PoE (Power over Ethernet) Gigabit Switches. PoE Gigabit Switches provide power for your Gigabit network devices, which are connected to your PoE switch. Connect access points, IP cameras and VOIP phones, which are PoE enabled, with a UTP cable (Cat 5, 5e or 6) to the PoE Gigabit switch. No additional power supplies are required for the connected devices. This is an ideal solution for SOHO (Small Office, Home Office) and business use.

Additional Information

Type	Switch
Lan Speed	10/100/1000

Operating System

This product does not depend on your operating system

Product Specification

EAN: 8716065315189
5 YEAR WARRANTY Dimensions in mm. (WxHxD): 179x44x280 Weight in grams: 1457 Standards : IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3af, IEEE802.3at, IEEE802.3ab Number of ports : 5 x 10/100/1000Mbps Auto-Negotiation ports Switching capacity : 10G Transfer method : Store-and-Forward PoE Power : Power+: pin 1 & pin 2, Power-: pin 3 & pin 6 Max PoE power : 26W for each PoE port, 75W for all PoE ports MAC address learning : Automatically learning, automatically Update 19" rack mountable
